Nestled in the heart of Abuja, Nwabali Aluminium stands as a trusted partner for industrial and construction needs. We are a premier Nigerian manufacturer and supplier, proudly providing high-quality aluminium solutions, including the exceptionally versatile Aluminium 5052 Chequered Plates. Our commitment is to deliver not just materials, but the foundation for stronger, safer, and more durable projects across the nation, backed by reliable service and deep industry expertise.
The composition of Aluminium 5052 is defined by its magnesium and chromium content, which is the key to its strength. This alloy offers excellent corrosion resistance, particularly in marine environments, and a notably high fatigue strength. It is not heat-treated but strengthened by cold working, resulting in a material that is both lightweight and remarkably durable, capable of withstanding significant stress without being brittle.
Standards : ASTM B209 / ASME SB209
Temper : O,H12,H14,H16,H18,H19,H22,H24,H26,H28,H32,H34,H36,H38,H111,H112,H114,H 116,H321
Thickness : 0.2-250
Width : 100-2600
Length : 500-10000
Surface : Bright, polished, hair line, brush, sand blast, embossed, etching, etc.
Finish :Mill, Customer specific finish
Aluminum Chequered Plate Coating : PVC Coated, Color Coated, Polyester, Fluorocarbon, polyurethane and epoxy coating
Type : Hot-Rolled (HR) / Cold-Rolled (CR) Chequered Plate
| European Standard | OLD | WNr | UNS | ISO | USA (AA) | GERMANY (DIN) |
| AW-AlMg2,5 | AG2,5C | 3.3523 | A95052 | AlMg2,5 | 5052 | AlMg2,5 |
| Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Al |
| 0.50 | 0.50 | 3.8/4.9 | 0.30/0.9 | 1.2/1.8 | 0.10 | 0.25 | 0.15 | Balance |
| Hardness, Brinell | Poisson’s Ratio | Melting Point | Electrical Resistivity | Modulus of Elasticity | Specific Heat |
| 47 | 0.33 | 607 – 649 °C | 4.99e-006 ohm-cm | 70.3 GPa | 0.88 J/g-°C |
Nwab Aluminium based in Abuja, Nigeria is a renowned manufacturer and supplier of premium aluminium products, including Aluminium Bars, Sheets and Plates, Coils, Chequered Plates, Wires, Pipes, Fittings, Flanges, Forging, Circle, Angles. With a commitment to delivering exceptional quality and service, we cater to diverse industries, offering reliable solutions tailored to specific requirements. Our products are known for their superior strength, corrosion resistance, and precise dimensions. We focus on customer satisfaction by providing an extensive range of aluminium bars designed for structural, industrial, and decorative applications.
Yes, we offer custom sizes for Aluminium 5052 Chequered Plates to meet specific project needs. Our team at Nwab Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@nwabalialuminium.com
These plates are the go-to choice for creating safe, non-slip surfaces in demanding environments. You will often find them used as flooring for trucks, trailers, and industrial walkways, as well as in marine applications like boat decks and offshore platforms. Their strength and durability also make them ideal for constructing ramps, stairs, and even certain types of architectural facades where both safety and aesthetics are important. They are the unseen strength in many modern structures.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
