Nwabali Aluminium stands out as a top-notch manufacturer and supplier of premium aluminium products right from Abuja, Nigeria. Known for its unwavering dedication to quality, precision engineering, and customer satisfaction, this company specializes in crafting Aluminium 1050 Channels that cater to a wide range of industrial and architectural needs. With state-of-the-art production facilities and a talented technical team, Nwabali Aluminium guarantees that each product adheres to international standards for strength, durability, and finish. Their Aluminium 1050 Channels are a go-to choice for the construction, automotive, and fabrication sectors across Nigeria, thanks to their outstanding performance, lightweight design, and resistance to corrosion.
Aluminium 1050 Channel is primarily made up of aluminium (at least 99.5%), along with small amounts of iron, silicon, copper, manganese, zinc, and titanium. This non-heat-treatable alloy is celebrated for its remarkable corrosion resistance, high ductility, and excellent thermal and electrical conductivity. It offers moderate strength, with a tensile strength typically ranging from 60 to 100 MPa, and is easy to work with for cold forming and welding. Plus, Aluminium 1050 Channels are highly reflective and maintain solid mechanical stability in both low and moderate temperature settings, making them versatile for various applications.
Specifications: ASTM B211 / ASME SB211
Temper: O, H12, H14, H16, H18, H22, H24, H26, H32, H112
Thickness: 0.91mm to 10 mm
Length: 10 to 12 Feet or as per clients’ requirement
Width: 9.5 mm X 9.5 mm To 150 mm X 75 mm or Custom
Finish: Mill, Customer specific finish
Surface: Anodize, powder coating, electrophoresis, PVDF coating, wood grain painting, matted, etc
Form: C-Channel, Box-Channel, U-Channel, J-Channel, Hat Channel, Strut Channels, Miscellaneous Channels
Alloy (ISS) | Equivalent alloy (A.A) | Copper | Magnesium | Silicon | Iron | Managanese Others* (Total) | Remarks | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Old | New | U.S.A | Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. | Max | Max. | Aluminum 99.0% Min. | ||
| 1 B | 19500 | 1050 | — | 0.05 | — | — | — | 0.30 | 0.4 | — | 0.05 | 0.1 | Aluminum 99.5% Min. | ||
| Alloy | Temper | UTS (Mpa) | Yield Strength (Mpa) | Elongation (%) | ||
|---|---|---|---|---|---|---|
| Minimum | Maximum | Minimum | Maximum | A 50mm (Minimum) | ||
| EN AW-1050 A | F | 60 | – | 20 | – | 23 |
| O | 60 | 95 | 20 | – | 23 | |
Nwab Aluminium based in Abuja, Nigeria is a renowned manufacturer and supplier of premium aluminium products, including Aluminium Bars, Sheets and Plates, Coils, Chequered Plates, Wires, Pipes, Fittings, Flanges, Forging, Circle, Angles. With a commitment to delivering exceptional quality and service, we cater to diverse industries, offering reliable solutions tailored to specific requirements. Our products are known for their superior strength, corrosion resistance, and precise dimensions. We focus on customer satisfaction by providing an extensive range of aluminium bars designed for structural, industrial, and decorative applications.
| European Standard | BS (OLD) | USA (AA) | GERMANY (DIN) | ISO | IS | Canadian | NORTH AMERICA | WNR |
|---|---|---|---|---|---|---|---|---|
| EN AW-1050 A | 1E | 1050 | Al99.5 | Al99.5 | 19500, 19501 | 1 S | UNS A91050 | 3.0255 |
Yes, we offer custom sizes for Aluminium 1050 Channel to meet specific project needs. Our team at Nwab Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@nwabalialuminium.com
These channels are widely embraced across different industries due to their lightweight characteristics, corrosion resistance, and superb formability. In construction, they find their place in framing, paneling, roofing trims, and architectural facades. The electrical sector utilizes them for bus bars, conductors, and enclosures, thanks to their excellent conductivity. They’re also prevalent in food processing, chemical, and signage industries where oxidation resistance and hygiene are crucial. Furthermore, Aluminium 1050 Channels are perfect for general fabrication, decorative trims, and protective edging, providing a cost-effective and durable solution for both industrial and aesthetic purposes.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
