Welcome to Nwabali Aluminium, your trusted partner for premium aluminium solutions right here in Abuja. We take pride in being a leading manufacturer and supplier, dedicated to providing local industries with top-tier materials. Our focus is on delivering high-quality Aluminium 6082 sheets and plates, backed by reliable service and deep industry expertise to support your most demanding projects and ensure your success.
The composition of Aluminium 6082 is primarily aluminium, strengthened with significant amounts of silicon and magnesium. This specific blend gives the alloy its excellent mechanical properties. It is known for having good formability and weldability, combined with medium strength. After a specific heat treatment process, it achieves even greater strength, making it a wonderfully versatile material that balances workability with impressive durability for a wide range of structural uses.
Standards : ASTM B209 / ASME SB209
Temper : O, T3,T4,T5, T6, T651 T6511
Thickness : 0.3-600
Width : 100-2600
Length : 500-10000
Surface : Bright, polished, hair line, brush, sand blast, embossed, etching, etc.
Finish :Mill, Customer specific finish
Aluminum Sheet/ Plate Coating : PVC Coated, Color Coated, Polyester, Fluorocarbon, polyurethane and epoxy coating
Type : Hot-Rolled (HR) / Cold-Rolled (CR) Sheet
| Weight% | Al | Si | Fe | Cu | Mn | Cr | Mg | Zn | Ti | Other Each | Others Total |
| Aluminium 6082 | Bal | 0.7 – 1.3 | 0.50 max | 0.10 max | 0.40-1.00 | 0.25 max | 0.06-1.20 | 0.20 max | 0.10 max | 0.05 max | 0.15 max |
| Tensile Strength, MPa | Yield Strength 0.2%, MPa | Elongation % | Hardness HBW |
| 295 | 240 | 8 | 95 |
Nwab Aluminium based in Abuja, Nigeria is a renowned manufacturer and supplier of premium aluminium products, including Aluminium Bars, Sheets and Plates, Coils, Chequered Plates, Wires, Pipes, Fittings, Flanges, Forging, Circle, Angles. With a commitment to delivering exceptional quality and service, we cater to diverse industries, offering reliable solutions tailored to specific requirements. Our products are known for their superior strength, corrosion resistance, and precise dimensions. We focus on customer satisfaction by providing an extensive range of aluminium bars designed for structural, industrial, and decorative applications.
| UNS | EN | DIN | ISO | BS (OLD) | USA | WNR |
| A96082 | AW-6082 | AlMgSi1 | Al Si1MgMn | HE30 | AA6082 | 3.2315 |
| Sizes (mm) | Theoretical Mass KG/Plate |
|---|---|
| 2000 X 1000 X 0.5 | 2500 X 1250 X 0.5 |
| 2000 X 1000 X 0.7 | 2500 X 1250 X 0.7 |
| 2000 X 1000 X 0.9 | 2500 X 1250 X 0.9 |
| 2000 X 1000 X 1.2 | 2500 X 1250 X 1.2 |
| 3000 X 1500 X 1.2 | 2000 X 1000 X 1.6 |
| 2500 X 1250 X 1.6 | 3000 X 1500 X 1.6 |
| 2000 X 1000 X 2.0 | 2500 X 1250 X 2.0 |
| 3000 X 1500 X 2.0 | 2500 X 1250 X 2.5 |
| 2.79 | 4.36 |
| 3.91 | 6.10 |
| 5.02 | 7.85 |
| 6.74 | 10.46 |
| 15.01 | 8.93 |
| 13.95 | 20.09 |
| 11.16 | 17.44 |
| 25.11 | 21.80 |
Yes, we offer custom sizes for Aluminium 6082 Sheets and Plates to meet specific project needs. Our team at Nwab Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@nwabalialuminium.com
You’ll find Aluminium 6082 sheets and plates at work in many essential applications. They are a fundamental material in the construction of bridges, towers, and various architectural structures. The transportation industry relies on them for building shipbuilding components, railway carriages, and heavy-duty vehicle frames. Beyond large-scale projects, they are also perfectly suited for crafting high-quality furniture, durable marine fittings, and even critical parts for the mining industry, proving their adaptability and strength across countless sectors.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
