Nwabali Aluminium has established itself as a trusted manufacturer and supplier right here in Abuja, providing industries across Nigeria with top-tier materials. We take particular pride in our Aluminium 1050 Circles, which are crafted to meet the highest standards of quality and consistency. Our commitment goes beyond just supply; we aim to be a reliable partner in your projects, ensuring you receive the right material with the precise specifications you need to drive your manufacturing and creative endeavors forward with confidence.
When we talk about Aluminium 1050 Circles, we’re referring to a material known for its exceptional purity, consisting of at least 99.5% aluminium. This composition gives it a wonderful combination of properties; it’s highly ductile, meaning it can be shaped and formed with relative ease without losing its integrity. It also boasts excellent corrosion resistance and high thermal and electrical conductivity. While it may not be the strongest alloy, its remarkable malleability and workability make it a favorite for processes that require intricate forming and deep drawing.
| Specifications | ASTM B209 / ASME SB209 |
|---|---|
| Temper | O,H12,H14,H16,H18,H19,H22,H24 |
| Thickness | 1 Mm To 100 mm |
| Diameter | Upto 2000 mm |
| Circle Diameter | 3″ DIA up to 38″ DIA 1500 lbs max |
| Circles Form | Hot Rolled Circles, Cold Rolled Circle, Proof Machined Circles |
| Finish | Mill, Customer specific finish |
| Aluminum Circle Coating | PVC Coated, Color Coated, Polyester, Fluorocarbon, polyurethane and epoxy coating |
| Alloy (ISS) | Equivalent alloy (A.A) | Copper | Magnesium | Silicon | Iron | Managanese Others* (Total) | Remarks | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Old | New | U.S.A | Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. | Max | Max. | Aluminum 99.0% Min. | ||
| 1 B | 19500 | 1050 | — | 0.05 | — | — | — | 0.30 | 0.4 | — | 0.05 | 0.1 | Aluminum 99.5% Min. | ||
| Alloy | Temper | UTS (Mpa) | Yield Strength (Mpa) | Elongation (%) | ||
|---|---|---|---|---|---|---|
| Minimum | Maximum | Minimum | Maximum | A 50mm (Minimum) | ||
| EN AW-1050 A | F | 60 | – | 20 | – | 23 |
| O | 60 | 95 | 20 | – | 23 | |
| European Standard | BS (OLD) | USA (AA) | GERMANY (DIN) | ISO | IS | Canadian |
|---|---|---|---|---|---|---|
| EN AW-1050 A | 1E | 1050 | Al99.5 | Al99.5 | 19500, 19501 | 1 S |
Nwab Aluminium based in Abuja, Nigeria is a renowned manufacturer and supplier of premium aluminium products, including Aluminium Bars, Sheets and Plates, Coils, Chequered Plates, Wires, Pipes, Fittings, Flanges, Forging, Circle, Angles. With a commitment to delivering exceptional quality and service, we cater to diverse industries, offering reliable solutions tailored to specific requirements. Our products are known for their superior strength, corrosion resistance, and precise dimensions. We focus on customer satisfaction by providing an extensive range of aluminium bars designed for structural, industrial, and decorative applications.
Yes, we offer custom sizes for Aluminium 1050 Circles to meet specific project needs. Our team at Nwab Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@nwabalialuminium.com
The versatility of Aluminium 1050 Circles opens doors to a wide array of practical applications. You’ll commonly find them being transformed into everyday essentials like pots, pans, and kitchen utensils, as well as specialized components such as reflectors, signage, and decorative panels. Their excellent conductivity makes them ideal for electrical busbars and other components, while their formability is perfect for creating spun hollowware and intricate light fittings. Essentially, wherever a project calls for a lightweight, corrosion-resistant, and easily fabricated material, these circles provide an outstanding solution.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
