In the heart of Nigeria’s bustling capital, Nwabali Aluminium stands as a trusted partner for industry, providing robust materials built to meet the demanding standards of modern engineering. We take pride in supplying high-grade Aluminium 7075 Flat Bars, a superior alloy chosen for projects where failure is not an option. Our commitment is to deliver not just a product, but a foundation of strength and reliability, supporting the ambitious builders and innovators shaping the future right here in Abuja and across the nation.
The exceptional strength of Aluminium 7075 comes from its sophisticated composition, primarily zinc as the main alloying element, supported by magnesium and copper. This blend gives the flat bars a remarkable toughness that rivals many types of steel, while retaining the invaluable lightweight characteristic of aluminium. It boasts excellent fatigue resistance and good mechanical properties, making it a go-to material for high-stress applications. This alloy is also known for its responsiveness to heat treatment, which further enhances its impressive durability and performance.
Standards : ASTM B221, B211, B565, B316, AMS 4121 7075
Temper : T3,T4,T5, T6, T651 T6511
Standard : ASTM, ASME, AMS, GB/T, JIS
Length : 100 mm To 3000 mm Long & Above, Random, Fix & Cut Length or as per clients’ requirement
Size : 5 mm To 500 mm
Finish : Bright, Polish & Black
Type : Hot-Rolled (HR) / Cold-Rolled (CR) Sheet
| Alloy | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Each | Total | ||||||||||
| Aluminium 7075 | Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| – | 0.40 | – | 0.50 | 1.20 | 2.00 | – | 0.30 | 2.10 | 2.90 | 0.18 | 0.28 | 5.10 | 6.10 | – | 0.20 | – | 0.05 | – | 0.15 | |
| Standard | Temper | Tensile | Hardness | ||||
| Aluminium 7075 | Ultimate | Yield | Elongation | Brinell | |||
| T6, T651, T6511 | KSI | MPA | KSI | MPA | % | ||
| 83 | 572 | 73 | 503 | 11 | 150 | ||
| 73 | 503 | 63 | 434 | 13 | N/A | ||
| European Standard | GERMANY | UNS | WERKSTOFF NR. |
| EN AW-7075 | AlZnMgCu1.5 | A97075 | 3.4365 |
Nwab Aluminium based in Abuja, Nigeria is a renowned manufacturer and supplier of premium aluminium products, including Aluminium Bars, Sheets and Plates, Coils, Chequered Plates, Wires, Pipes, Fittings, Flanges, Forging, Circle, Angles. With a commitment to delivering exceptional quality and service, we cater to diverse industries, offering reliable solutions tailored to specific requirements. Our products are known for their superior strength, corrosion resistance, and precise dimensions. We focus on customer satisfaction by providing an extensive range of aluminium bars designed for structural, industrial, and decorative applications.
Yes, we offer custom sizes for Aluminium 7075 Flat Bars to meet specific project needs. Our team at Nwab Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@nwabalialuminium.com
The unique properties of these flat bars make them indispensable in fields where every gram and every ounce of strength counts. You’ll find them at the core of aerospace components, in critical aircraft parts, and within high-performance automotive frames. Beyond transportation, they are essential for designing durable military equipment, robust machinery frames, and even high-end sporting goods like mountain bike components. Essentially, any application demanding a perfect balance of light weight and exceptional strength is an ideal candidate for Aluminium 7075 flat bars.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
