Nwabali Aluminium, a trusted manufacturer and supplier right here in Abuja, Nigeria, takes pride in bringing exceptional strength to your doorstep with our Aluminium 7075 Chequered Plates. We understand that local projects demand world-class materials, which is why we specialize in this high-performance alloy. Whether you’re an engineer, fabricator, or builder, we offer a reliable source for plates that combine superior durability with the safety-enhancing grip of a chequered pattern, ensuring your structures are built to last and operate safely in demanding environments.
The exceptional strength of Aluminium 7075 stems from its sophisticated composition, primarily zinc, along with magnesium and copper. This specific blend gives these plates remarkable mechanical properties, making them comparable to many types of steel in terms of their toughness. They boast an outstanding strength-to-weight ratio, excellent fatigue resistance, and good mechanical workability. This unique combination means you get a material that is incredibly strong and durable yet relatively lightweight, offering a significant advantage for applications where every kilogram counts without sacrificing performance.
Standards : ASTM B209 / ASME SB209
Temper : T3, T4, T5, T6, T651, T6511
Thickness : 0.2-300
Width : 100-2600
Length : 500-10000
Surface : Bright, polished, hair line, brush, sand blast, embossed, etching, etc.
Finish :Mill, Customer specific finish
Aluminum Chequered Plate Coating : PVC Coated, Color Coated, Polyester, Fluorocarbon, polyurethane and epoxy coating
Type : Hot-Rolled (HR) / Cold-Rolled (CR) Chequered Plate
| UNS | EN | DIN,WNr | JIS | AFNOR | ISO | BS | GOST |
| A97075 | ENAW-AlZn5.5MgCu EN AW-7075 | 3.4365 AlZnMgCu1.5 | 7075 | 7075 A-Z5GU | AlZn6MgCu | 7075 L95 L96 | V95 |
| Weight % | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Each | Total |
| Minimum | 1.20 | 2.10 | 0.18 | 5.10 | ||||||
| Maximum | 0.40 | 0.50 | 2.00 | 0.30 | 2.90 | 0.28 | 6.10 | 0.20 | 0.05 | 0.15 |
| Temper | Tensile | Hardness | ||||
| Ultimate | Yield | Elongation | Brinell | |||
| KSI | MPA | KSI | MPA | % | ||
| T6, T651 | 83 | 572 | 73 | 503 | 11 | 150 |
| T73, T7351 | 73 | 503 | 63 | 434 | 13 | N/A |
Nwab Aluminium based in Abuja, Nigeria is a renowned manufacturer and supplier of premium aluminium products, including Aluminium Bars, Sheets and Plates, Coils, Chequered Plates, Wires, Pipes, Fittings, Flanges, Forging, Circle, Angles. With a commitment to delivering exceptional quality and service, we cater to diverse industries, offering reliable solutions tailored to specific requirements. Our products are known for their superior strength, corrosion resistance, and precise dimensions. We focus on customer satisfaction by providing an extensive range of aluminium bars designed for structural, industrial, and decorative applications.
Yes, we offer custom sizes for Aluminium 7075 Chequered Plates to meet specific project needs. Our team at Nwab Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@nwabalialuminium.com
The unique blend of strength, lightness, and a secure, non-slip surface makes these plates incredibly versatile. You will commonly find them underfoot in critical areas like aircraft flooring, marine vessel decks, and the treads of industrial stairways and platforms where safety is paramount. Beyond walkways, they are a preferred material for constructing robust truck bodies, high-stress machinery parts, and even in the defense and aerospace industries. Essentially, wherever a project demands a material that can handle heavy loads, resist wear, and prevent slips, Aluminium 7075 Chequered Plates are an outstanding choice.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
