Nestled in the heart of Abuja, Nwabali Aluminium stands as a trusted name for quality and reliability. We take pride in supplying and manufacturing premium aluminium solutions, with our Aluminium 7050 Chequered Plates representing a cornerstone of our strong, durable product line. Designed to meet the rigorous demands of both industrial and commercial applications, these plates are a testament to our commitment to bringing world-class materials to Nigeria’s growing infrastructure and construction landscape.
Crafted from the 7050 aluminium alloy, these plates boast an excellent composition rich with zinc, magnesium, and copper. This specific blend is engineered to achieve an exceptional strength-to-weight ratio. The material is further enhanced through a controlled tempering process, which significantly boosts its mechanical properties. The result is a plate with superior tensile strength and impressive resistance to stress corrosion cracking, making it exceptionally tough and reliable for heavy-duty use in challenging environments.
Standards : ASTM B209 / ASME SB209
Temper : T3, T4, T5, T6, T651 T6511
Thickness : 0.2-300
Width : 100-2600
Length : 500-10000
Surface : Bright, polished, hair line, brush, sand blast, embossed, etching, etc.
Finish :Mill, Customer specific finish
Aluminum Chequered Plate Coating : PVC Coated, Color Coated, Polyester, Fluorocarbon, polyurethane and epoxy coating
Type : Hot-Rolled (HR) / Cold-Rolled (CR) Chequered Plate
| UNS | EN | DIN,WNr | ISO |
| A97050 | EN3982 | 3.4144 | AlZn6CuMgZr |
| Weight % | Zn | Cu | Mg | Zr | Fe | Si | Mn | Ti | Cr | Others (total) |
| Minimum | 5.7 | 2.0 | 1.9 | 0.08 | – | – | – | – | – | – |
| Maximum | 6.7 | 2.6 | 2.6 | 0.15 | 0.15 | 0.12 | 0.10 | 0.06 | 0.04 | 0.15 |
| Material | Temper | Tensile Strength (ksi) | Yield Strength (ksi) | Elongation in 2″ % |
| Aluminium Alloy 7050 Angle (AMS 4340) | T76511 | 79 | 69 | 7 |
| Aluminium Alloy 7050 Angle (AMS 4340) | T73511 | 70 | 60 | 8 |
| Aluminium Alloy 7050 Angle (AMS 4342) | T74511 | 73 | 63 | 7 |
Nwab Aluminium based in Abuja, Nigeria is a renowned manufacturer and supplier of premium aluminium products, including Aluminium Bars, Sheets and Plates, Coils, Chequered Plates, Wires, Pipes, Fittings, Flanges, Forging, Circle, Angles. With a commitment to delivering exceptional quality and service, we cater to diverse industries, offering reliable solutions tailored to specific requirements. Our products are known for their superior strength, corrosion resistance, and precise dimensions. We focus on customer satisfaction by providing an extensive range of aluminium bars designed for structural, industrial, and decorative applications.
Yes, we offer custom sizes for Aluminium 7050 Chequered Plates to meet specific project needs. Our team at Nwab Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@nwabalialuminium.com
The unique chequered pattern on these plates is a masterstroke of functional design, providing essential slip resistance even in wet or oily conditions. This makes them the ideal choice for flooring in factories, workshops, and on industrial platforms. Beyond flooring, their high strength and durability see them used for truck decks, trailer floors, and even in the construction of bridges and marine applications. Essentially, anywhere a combination of immense strength, safety, and longevity is required, these plates prove to be an indispensable asset.
