Nwabali Aluminium stands as a trusted partner for quality and reliability in Abuja’s construction and manufacturing sectors. We take pride in supplying premium Aluminium 6063 sheets and plates, materials chosen for their exceptional workability and sleek finish. Our commitment goes beyond just delivering products; we provide durable, versatile solutions that empower local builders, fabricators, and architects to bring their most ambitious projects to life with confidence and precision, right here in Nigeria.
Aluminium 6063 is known for its excellent blend of strength and formability, a result of its magnesium and silicon composition. This alloy is naturally resistant to corrosion and responds beautifully to anodizing, which enhances both its appearance and surface durability. While it may not be the strongest aluminium option, its superb extrudability makes it a favorite for creating complex, detailed shapes without compromising on a smooth, architectural-grade finish that stands the test of time.
Standards : ASTM B209 / ASME SB209
Temper : O, T3,T4,T5, T6, T651 T6511
Thickness : 0.3-600
Width : 100-2600
Length : 500-10000
Surface : Bright, polished, hair line, brush, sand blast, embossed, etching, etc.
Finish :Mill, Customer specific finish
Aluminum Sheet/ Plate Coating : PVC Coated, Color Coated, Polyester, Fluorocarbon, polyurethane and epoxy coating
Type : Hot-Rolled (HR) / Cold-Rolled (CR) Sheet
| Cu | Si | Fe | Mn | Mg | Zn | Cr | Ti | Other Each | Others Total | Al |
| .10 (max) | .20/.60 | .35 (max) | .10 (max) | .45/.90 | .10 (max) | .10 (max) | .10 (max) | .05 | .015 | Remainder |
| Tensile Strength (psi) | Yield Strength (psi) | Elongation (% in 2″) | Brinell Hardness |
| 27,000 | 21,000 | 12 | 60 |
Nwab Aluminium based in Abuja, Nigeria is a renowned manufacturer and supplier of premium aluminium products, including Aluminium Bars, Sheets and Plates, Coils, Chequered Plates, Wires, Pipes, Fittings, Flanges, Forging, Circle, Angles. With a commitment to delivering exceptional quality and service, we cater to diverse industries, offering reliable solutions tailored to specific requirements. Our products are known for their superior strength, corrosion resistance, and precise dimensions. We focus on customer satisfaction by providing an extensive range of aluminium bars designed for structural, industrial, and decorative applications.
| UNS | EN | DIN | ISO | BS (OLD) | USA | WNR |
| A96063 | AW-AlMg0,7Si EN AW-6063 | AlMgSi0.5 | AlMg0,7Si | HE9 | AA6063 | 3.32206 |
| Sizes (mm) | Theoretical Mass KG/Plate |
|---|---|
| 2000 X 1000 X 0.5 | 2500 X 1250 X 0.5 |
| 2000 X 1000 X 0.7 | 2500 X 1250 X 0.7 |
| 2000 X 1000 X 0.9 | 2500 X 1250 X 0.9 |
| 2000 X 1000 X 1.2 | 2500 X 1250 X 1.2 |
| 3000 X 1500 X 1.2 | 2000 X 1000 X 1.6 |
| 2500 X 1250 X 1.6 | 3000 X 1500 X 1.6 |
| 2000 X 1000 X 2.0 | 2500 X 1250 X 2.0 |
| 3000 X 1500 X 2.0 | 2500 X 1250 X 2.5 |
| 2.79 | 4.36 |
| 3.91 | 6.10 |
| 5.02 | 7.85 |
| 6.74 | 10.46 |
| 15.01 | 8.93 |
| 13.95 | 20.09 |
| 11.16 | 17.44 |
| 25.11 | 21.80 |
Yes, we offer custom sizes for Aluminium 6063 Sheets and Plates to meet specific project needs. Our team at Nwab Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@nwabalialuminium.com
The versatility of these sheets and plates makes them a common sight in both architectural and general fabrication. They are the ideal choice for crafting sleek window and door frames, elegant curtain wall systems, and durable roofing solutions. Beyond buildings, this material is widely used for creating sturdy furniture, decorative trims, and a variety of consumer goods, proving its value wherever a combination of good looks, light weight, and dependable performance is required.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
